Non-management VDOMs send logs to both global and vdom-override syslog servers

This information is also available in the FortiOS 7.6 Administration Guide: Configuring syslog overrides for VDOMs

FortiOS can now send logs from non-management VDOMs to both global and VDOM-override syslog servers. Previously, configuring an override syslog server under a non-management VDOM would halt the transmission of logs to the global syslog server. The new update ensures uninterrupted log transmission to the global server, enhancing the log management experience.

The config log syslogd override-setting command includes a new option:

config log syslogd override-setting
    set use-management-vdom {enable | disable}
end

set use-management-vdom {enable | disable}

Enable/disable use of management VDOM as source VDOM for logs sent to syslog server. enable: Send logs through the management VDOM. disable: Do not send logs through the management VDOM.

When use-management-vdom is enabled under non-management VDOM, only the management VDOM is used to forward logs to configured syslog servers. Non-management VDOM override syslog servers must be reachable through the management VDOM.

Example

This example covers the following scenarios:

• Non-management VDOM with use-management-vdom disabled

• Non-management VDOM with use-management-vdom enabled

• Non-management VDOM with mix of use-management-vdom enabled and disabled

All scenarios use the following IP addresses:

• Global syslog server: 10.6.30.22

• Root VDOM gateway: 192.168.5.254

• Management VDOM (vdom1) gateway: 172.16.200.254

Non-management VDOM with use-management-vdom disabled

In this example, a global syslog server is enabled. For the root VDOM, an override syslog server is enabled with use-management-vdom disabled. For the management VDOM, an override syslog server is enabled. With this configuration, logs are sent to the following locations:

• All VDOMs, except the root and management VDOMs, send logs to the global syslog server (10.6.30.22).

• The root VDOM sends logs to its override syslog server at 192.168.5.44.

• The management VDOM sends logs to its override syslog server at 172.16.200.55.

To configure syslog servers:

1. Enable the global syslog server:

   config log syslogd setting
       set status enable
       set server "10.6.30.22"
       set facility local6
   end

2. For the root VDOM, enable an override syslog server and disable use-management-vdom:

   config log syslogd override-setting
       set status enable
       set server "192.168.5.44"
       set use-management-vdom disable
       set facility local6
   end

3. For the management VDOM (vdom1), enable an override syslog server:

   config log syslogd override-setting
       set status enable
       set server "172.16.200.55"
       set facility local6
   end

Non-management VDOM with use-management-vdom enabled

In this example, a global syslog server is enabled. For the root VDOM, an override syslog server and use-management-vdom are enabled. For the management VDOM, two override syslog servers are enabled. With this configuration, logs are sent to the following locations:

• All VDOMs, except root and management VDOMs, send logs to the global syslog server (10.6.30.22).

• The root VDOM cannot send logs to syslog servers because the servers are not reachable through the management VDOM.

  To send logs to 192.168.5.44, set use-management-vdom to disable for the root VDOM. Alternately, configure the root VDOM to use an override syslog server that is reachable through the management VDOM.

• The management VDOM sends logs to the override syslog server at 172.16.200.55.

To configure syslog servers:

1. Enable the global syslog server:

   config log syslogd setting
       set status enable
       set server "10.6.30.22"
       set facility local6
   end

2. For the root VDOM, enable an override syslog server and enable use-management-vdom:

   config log syslogd override-setting
       set status enable
       set server "192.168.5.44"
       set use-management-vdom enable
       set facility local6
   end

3. For the management VDOM, enable an override syslog server:

   config log syslogd override-setting
       set status enable
       set server "172.16.200.55"
       set facility local6
   end

Non-management VDOM with mix of use-management-vdom enabled and disabled

In this example, a global syslog server is enabled. For the root VDOM, three override syslog servers are enabled with a mix of use-management-vdom set to enabled and disabled. For the management VDOM, an override syslog server is enabled. With this configuration, logs are sent from non-management VDOMs to both global and VDOM-override syslog servers. The logs are sent to the following locations:

• All VDOMs, except the root and management VDOMs, send logs to the global syslog server (10.6.30.22).

• The root VDOM sends logs to the following syslog servers:

  • For syslogd, logs are sent to the root VDOM override server at 192.168.5.44 because use-management-vdom is disabled.

  • For syslogd2, logs are sent through the management VDOM to the root VDOM override server at 172.16.200.55 and to the syslog server reachable by the management VDOM because use-management-vdom is enabled.

  • For syslogd3, logs are sent through the management VDOM to the root VDOM override syslog server at 10.6.30.22 and to the syslog server reachable by the management VDOM because use-management-vdom is enabled.

• The management VDOM (vdom1) sends logs to the override syslog server at 172.16.200.55.

To configure syslog servers:

1. Enable the global syslog server:

   config log syslogd setting
       set status enable
       set server "10.6.30.22"
       set facility local6
   end

2. For root, configure three override syslog servers:

   1. For syslogd, enable an override syslog server and disable use-management-vdom:

      config log syslogd override-setting
          set status enable
          set server "192.168.5.44"
          set use-management-vdom disable
          set facility local6
      end

   2. For syslog2, enable an override syslog server and enable use-management-vdom:

      config log syslogd2 override-setting
          set status enable
          set server "172.16.200.55"
          set use-management-vdom enable
          set facility local6
      end

   3. For syslog3, enable an override syslog server and enable use-management-vdom:

      config log syslogd3 override-setting
          set status enable
          set server "10.6.30.22"
          set use-management-vdom enable
      end

3. For the management VDOM, configure an override syslog server:

   config log syslogd override-setting
       set status enable
       set server "172.16.200.55"
       set facility local6
   end
