Widget actions
The top banner on each widget provides some or all of the following controls:
- Drill-down: View drill-down data.
- Refresh: Refresh the data.
- action : Edit or delete the widget
- Drag to reorder: Select then drag and drop to change the position of a widget in the pane
|
Hover over the widgets to see additional information. |
Edit actions
Selecting Edit in the action dropdown opens a window within the widget that allows you to select the chart type, top N results, and how to sort the data.
Drill-down capability
The drill-down icon (
) indicates that you can get more information about the data displayed in the widget.
The following widgets support the drill-down capability:
- Top Countries
- Top Threats
- Top Sources
- Top Destinations
- Top Applications
Each of these widgets displays a graph or bar chart with the top N results, where the result is a region, traffic, or intrusion prevention (depending on the widget). When you select one of the results, the Logs tab opens with a view filtered by that result. The view filter is listed above the table.
